Cervelo R5 (2022) - Geometry
Compare these geometries with each other
The table can be moved.
| Modell | Cervelo R5 (2022) | Cervelo R5 (2022) | Cervelo R5 (2022) | Cervelo R5 (2022) | Cervelo R5 (2022) | Cervelo R5 (2022) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | 48 | 51 | 54 | 56 | 58 | 61 |
| Typ | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 363 mm | 371 mm | 380 mm | 389 mm | 398 mm | 407 mm |
| Stack | 497 mm | 522 mm | 547 mm | 572 mm | 597 mm | 622 mm |
| STR | 1,37 | 1,41 | 1,44 | 1,47 | 1,50 | 1,53 |
| Reach+ | ||||||
| Stack+ | ||||||
| Front-Center | ||||||
| Head Angle | 71° | 72° | 73° | 73° | 73° | 73° |
| Seat Angle, effective | ||||||
| Seat Angle, real | 73° | 73° | 73° | 73° | 73° | 73° |
| Top Tube Length | ||||||
| Top Tube Length (horizontal) | 515 mm | 531 mm | 548 mm | 564 mm | 581 mm | 598 mm |
| Head Tube Length | 93 mm | 114 mm | 137 mm | 163 mm | 192 mm | 218 mm |
| Seat Tube Length | 403 mm | 434 mm | 463 mm | 486 mm | 503 mm | 526 mm |
| Standover Height | 695 mm | 724 mm | 755 mm | 778 mm | 800 mm | 824 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 972 mm | 974 mm | 977 mm | 994 mm | 1.011 mm | 1.028 mm |
| Bottom Bracket Drop | 74.5 mm | 74.5 mm | 72 mm | 72 mm | 69.5 mm | 69.5 mm |
| Bottom Bracket Height | ||||||
| Fork installation height | ||||||
| Fork offset | 57.5 mm | 51.5 mm | 45.5 mm | 45.5 mm | 45.5 mm | 45.5 mm |
| Fork caster | ||||||
| Travel (rear) | ||||||
| Travel (front) |
