Canyon Spectral 29 160 (2021) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Canyon Spectral 29 160 (2021) | Canyon Spectral 29 160 (2021) | Canyon Spectral 29 160 (2021) | Canyon Spectral 29 160 (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 435 mm 435 mm | 460 mm 460 mm | 485 mm 485 mm | 510 mm 510 mm |
| Stack | 610 mm 610 mm | 619 mm 619 mm | 628 mm 628 mm | 637 mm 637 mm |
| STR | 1.40 1.40 | 1.35 1.35 | 1.29 1.29 | 1.25 1.25 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 749 mm 749 mm | 771 mm 771 mm | 793 mm 793 mm | 816 mm 816 mm |
| Frame RAAD | 35.5° 35.5° | 36.6° 36.6° | 37.7° 37.7° | 38.7° 38.7° |
| Front-Center | ||||
| Head Angle | 64.5° 64° | 64.5° 64° | 64.5° 64° | 64.5° 64° |
| Seat Angle, effective | 76.5° 76° | 76.5° 76° | 76.5° 76° | 76.5° 76° |
| Seat Angle, real | ||||
| Top Tube Length | 582 mm 582 mm | 609 mm 609 mm | 636 mm 636 mm | 663 mm 663 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 95 mm 95 mm | 105 mm 105 mm | 115 mm 115 mm | 125 mm 125 mm |
| Seat Tube Length | 395 mm 395 mm | 430 mm 430 mm | 460 mm 460 mm | 490 mm 490 mm |
| Standover Height | ||||
| Chainstay Length | 437 mm 437 mm | 437 mm 437 mm | 437 mm 437 mm | 437 mm 437 mm |
| Wheelbase | 1,195 mm 1,195 mm | 1,224 mm 1,224 mm | 1,253 mm 1,253 mm | 1,283 mm 1,283 mm |
| FC2RC | 1.73 1.73 | 1.80 1.80 | 1.87 1.87 | 1.94 1.94 |
| Bottom Bracket Drop | 28 mm 36 mm | 28 mm 36 mm | 28 mm 36 mm | 28 mm 36 mm |
| Bottom Bracket Height | ||||
| Fork installation height | 571 mm 571 mm | 571 mm 571 mm | 571 mm 571 mm | 571 mm 571 mm |
| Fork offset | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm | 44 mm 44 mm |
| Trail | ||||
| Travel (rear) | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm | 150 mm 150 mm |
| Travel (front) | 160 mm 160 mm | 160 mm 160 mm | 160 mm 160 mm | 160 mm 160 mm |
