Canyon Neuron (2021) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Canyon Neuron (2021) | Canyon Neuron (2021) | Canyon Neuron (2021) |
|---|---|---|---|
| Frame Size/Setup | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 428 mm | 448 mm | 468 mm |
| Stack | 617 mm | 627 mm | 655 mm |
| STR | 1.44 | 1.40 | 1.40 |
| Reach+ | |||
| Stack+ | |||
| Frame RAD | 751 mm | 771 mm | 805 mm |
| Frame RAAD | 34.7° | 35.5° | 35.5° |
| Front-Center | |||
| Head Angle | 67° | 67° | 67° |
| Seat Angle, effective | 74° | 74° | 74° |
| Seat Angle, real | |||
| Top Tube Length | 603 mm | 626 mm | 654 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 102 mm | 112 mm | 143 mm |
| Seat Tube Length | 445 mm | 480 mm | 520 mm |
| Standover Height | |||
| Chainstay Length | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1,170 mm | 1,193 mm | 1,225 mm |
| FC2RC | 1.66 | 1.71 | 1.78 |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Trail | |||
| Travel (rear) | 130 mm | 130 mm | 130 mm |
| Travel (front) | 140 mm | 140 mm | 140 mm |
