Canyon Lux CF SLX (2019) - Geometry

Compare these geometries with each other

The table can be moved.
Modell Canyon Lux CF SLX (2019) Canyon Lux CF SLX (2019) Canyon Lux CF SLX (2019) Canyon Lux CF SLX (2019)
Frame Size/Setup S M L XL
Typ Mountainbike Mountainbike Mountainbike Mountainbike
Wheel Size 29″ 29″ 29″ 29″
Reach 415 mm 435 mm 455 mm 475 mm
Stack 582 mm 591 mm 605 mm 629 mm
STR 1,40 1,36 1,33 1,32
Reach+
Stack+
Front-Center
Head Angle 70° 70° 70° 70°
Seat Angle, effective 74.5° 74.5° 74.5° 74.5°
Seat Angle, real
Top Tube Length 576 mm 599 mm 623 mm 649 mm
Top Tube Length (horizontal)
Head Tube Length 90 mm 100 mm 115 mm 140 mm
Seat Tube Length 425 mm 465 mm 505 mm 545 mm
Standover Height 786 mm 789 mm 796 mm 811 mm
Chainstay Length 435 mm 435 mm 435 mm 435 mm
Wheelbase 1.102 mm 1.126 mm 1.151 mm 1.179 mm
Bottom Bracket Drop 38 mm 38 mm 38 mm 38 mm
Bottom Bracket Height
Fork installation height 504 mm 504 mm 504 mm 504 mm
Fork offset 44 mm 44 mm 44 mm 44 mm
Fork caster
Travel (rear) 100 mm 100 mm 100 mm 100 mm
Travel (front) 100 mm 100 mm 100 mm 100 mm
