Compare these geometries with each other
| Modell | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) | Canyon Aeroad CF SLX / CF SL / CFR (2021) |
|---|---|---|---|---|---|---|---|---|
| Frame Size/Setup | 3XS | 2XS | XS | S | M | L | XL | XXL |
| Typ | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad | Rennrad |
| Wheel Size | 27,5″ / 650B | 27,5″ / 650B | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 358 mm | 372 mm | 372 mm | 390 mm | 393 mm | 401 mm | 419 mm | 429 mm |
| Stack | 483 mm | 498 mm | 521 mm | 539 mm | 560 mm | 580 mm | 606 mm | 624 mm |
| STR | 1,35 | 1,34 | 1,40 | 1,38 | 1,42 | 1,45 | 1,45 | 1,45 |
| Front-Center | ||||||||
| Head Angle | 71° | 71.5° | 71.5° | 72.25° | 73.25° | 73.25° | 73.5° | 73.75° |
| Seat Angle, effective | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° | 73.5° |
| Seat Angle, real | ||||||||
| Top Tube Length | 501 mm | 520 mm | 533 mm | 549 mm | 559 mm | 572 mm | 598 mm | 613 mm |
| Top Tube Length (horizontal) | ||||||||
| Head Tube Length | 103 mm | 121 mm | 109 mm | 126 mm | 147 mm | 167 mm | 193 mm | 211 mm |
| Seat Tube Length | 413 mm | 443 mm | 473 mm | 503 mm | 533 mm | 563 mm | 593 mm | 623 mm |
| Standover Height | ||||||||
| Chainstay Length | 405 mm | 405 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 951 mm | 967 mm | 977 mm | 984 mm | 989 mm | 1.002 mm | 1.025 mm | 1.038 mm |
| Bottom Bracket Drop | ||||||||
| Bottom Bracket Height | ||||||||
| Fork installation height | ||||||||
| Fork offset | ||||||||
| Fork caster | ||||||||
| Travel (rear) | ||||||||
| Travel (front) |
