Cannondale Topstone Carbon Lefty (2023) - Geometry
Compare these geometries with each other
The table can be moved.
| Modell | Cannondale Topstone Carbon Lefty (2023) | Cannondale Topstone Carbon Lefty (2023) | Cannondale Topstone Carbon Lefty (2023) | Cannondale Topstone Carbon Lefty (2023) | Cannondale Topstone Carbon Lefty (2023) |
|---|---|---|---|---|---|
| Frame Size/Setup | XS | SM | MD | LG | XL |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 361 mm | 367 mm | 373 mm | 379 mm | 386 mm |
| Stack | 539 mm | 555 mm | 579 mm | 605 mm | 629 mm |
| STR | 1,49 | 1,51 | 1,55 | 1,60 | 1,63 |
| Reach+ | |||||
| Stack+ | |||||
| Front-Center | |||||
| Head Angle | 69.3° | 70.3° | 70.5° | 70.5° | 70.5° |
| Seat Angle, effective | 72.4° | 72.4° | 72.4° | 72.4° | 72.4° |
| Seat Angle, real | 70.7° | 70.9° | 71.1° | 71.2° | 71.4° |
| Top Tube Length | |||||
| Top Tube Length (horizontal) | 532 mm | 543 mm | 556 mm | 571 mm | 586 mm |
| Head Tube Length | 105 mm | 123 mm | 150 mm | 177 mm | 205 mm |
| Seat Tube Length | 410 mm | 458 mm | 505 mm | 553 mm | 590 mm |
| Standover Height | 710 mm | 751 mm | 791 mm | 829 mm | 864 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 1.012 mm | 1.016 mm | 1.030 mm | 1.046 mm | 1.062 mm |
| Bottom Bracket Drop | 69 mm | 64 mm | 61 mm | 61 mm | 59 mm |
| Bottom Bracket Height | |||||
| Fork installation height | |||||
| Fork offset | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Fork caster | 74 mm | 67 mm | 66 mm | 66 mm | 66 mm |
| Travel (rear) | |||||
| Travel (front) |
