Cannondale Scalpel HT 110 (2022) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | Cannondale Scalpel HT 110 (2022) | Cannondale Scalpel HT 110 (2022) | Cannondale Scalpel HT 110 (2022) | Cannondale Scalpel HT 110 (2022) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 404 mm | 423 mm | 444 mm | 465 mm |
| Stack | 607 mm | 617 mm | 629 mm | 641 mm |
| STR | 1.50 | 1.46 | 1.42 | 1.38 |
| Reach+ | ||||
| Stack+ | ||||
| Frame RAD | 729 mm | 748 mm | 770 mm | 792 mm |
| Frame RAAD | 33.6° | 34.4° | 35.2° | 36° |
| Front-Center | ||||
| Head Angle | 66.5° | 66.5° | 66.5° | 66.5° |
| Seat Angle, effective | 74.5° | 74.5° | 74.5° | 74.5° |
| Seat Angle, real | 72.7° | 73.5° | 74.1° | 74.6° |
| Top Tube Length | ||||
| Top Tube Length (horizontal) | 572 mm | 594 mm | 617 mm | 642 mm |
| Head Tube Length | 99 mm | 110 mm | 122 mm | 135 mm |
| Seat Tube Length | 390 mm | 440 mm | 480 mm | 530 mm |
| Standover Height | 754 mm | 790 mm | 819 mm | 855 mm |
| Chainstay Length | 430 mm | 435 mm | 440 mm | 445 mm |
| Wheelbase | 1,123 mm | 1,151 mm | 1,181 mm | 1,212 mm |
| FC2RC | 1.61 | 1.65 | 1.68 | 1.72 |
| Bottom Bracket Drop | 59 mm | 59 mm | 59 mm | 59 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm | 318 mm |
| Fork installation height | ||||
| Fork offset | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | ||||
| Travel (rear) | ||||
| Travel (front) | 110 mm | 110 mm | 110 mm | 110 mm |
