Compare these geometries with each other
| Modell | Cannondale Scalpel (2021) | Cannondale Scalpel (2021) | Cannondale Scalpel (2021) | Cannondale Scalpel (2021) |
|---|---|---|---|---|
| Frame Size/Setup | S | M | L | XL |
| Typ | Mountainbike | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ | 29″ |
| Reach | 415 mm | 435 mm | 455 mm | 475 mm |
| Stack | 582 mm | 591 mm | 601 mm | 610 mm |
| STR | 1,40 | 1,36 | 1,32 | 1,28 |
| Front-Center | ||||
| Head Angle | 68° | 68° | 68° | 68° |
| Seat Angle, effective | 74.5° | 74.5° | 74.5° | 74.5° |
| Seat Angle, real | ||||
| Top Tube Length | 576 mm | 599 mm | 622 mm | 644 mm |
| Top Tube Length (horizontal) | ||||
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Seat Tube Length | 430 mm | 440 mm | 480 mm | 520 mm |
| Standover Height | 743 mm | 745 mm | 745 mm | 748 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1.128 mm | 1.151 mm | 1.175 mm | 1.199 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Bottom Bracket Height | 331 mm | 331 mm | 331 mm | 331 mm |
| Fork installation height | ||||
| Fork offset | 55 mm | 55 mm | 55 mm | 55 mm |
| Fork caster | ||||
| Travel (rear) | 100 mm | 100 mm | 100 mm | 100 mm |
| Travel (front) | 100 mm | 100 mm | 100 mm | 100 mm |
