Compare these geometries with each other
| Modell | Bold Unplugged Vol.1 (2021) | Bold Unplugged Vol.1 (2021) | Bold Unplugged Vol.1 (2021) |
|---|---|---|---|
| Frame Size/Setup | S | M | L |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ 29″ | 29″ 29″ | 29″ 29″ |
| Reach | 406.8 mm 424.2 mm | 458.3 mm 474.9 mm | 498 mm 513.7 mm |
| Stack | 599.8 mm 611.7 mm | 599.9 mm 612.4 mm | 617.8 mm 631.2 mm |
| STR | 1,47 1,44 | 1,31 1,29 | 1,24 1,23 |
| Front-Center | |||
| Head Angle | 63.3° 65.9° | 63.3° 65.9° | 63.3° 65.9° |
| Seat Angle, effective | 75.5° 77.4° | 76.5° 78.3° | 76.5° 78.3° |
| Seat Angle, real | |||
| Top Tube Length | 558.9 mm 565.4 mm | 599.1 mm 605.1 mm | 641.3 mm 647.4 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 90 mm 90 mm | 90 mm 90 mm | 110 mm 110 mm |
| Seat Tube Length | |||
| Standover Height | |||
| Chainstay Length | 432.8 mm 443.6 mm | 432.8 mm 443.6 mm | 432.8 mm 443.6 mm |
| Wheelbase | 1.175 mm 1.203 mm | 1.226 mm 1.254 mm | 1.273 mm 1.301 mm |
| Bottom Bracket Drop | 8.4 mm 27.3 mm | 8.4 mm 27.5 mm | 8.7 mm 28 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 161 mm 165 mm | 161 mm 165 mm | 161 mm 165 mm |
| Travel (front) | 170 mm 170 mm | 170 mm 170 mm | 170 mm 170 mm |
