Compare these geometries with each other
| Modell | Bold Linkin Trail Classic (2021) | Bold Linkin Trail Classic (2021) | Bold Linkin Trail Classic (2021) |
|---|---|---|---|
| Frame Size/Setup | S | M | L |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 395 mm | 425 mm | 451 mm |
| Stack | 601 mm | 612 mm | 633 mm |
| STR | 1,52 | 1,44 | 1,40 |
| Front-Center | |||
| Head Angle | 67.8° | 67.8° | 67.8° |
| Seat Angle, effective | 74° | 74° | 74° |
| Seat Angle, real | |||
| Top Tube Length | 563 mm | 596 mm | 628 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 90 mm | 101 mm | 124 mm |
| Seat Tube Length | 415 mm | 430 mm | 480 mm |
| Standover Height | 706 mm | 728 mm | 760 mm |
| Chainstay Length | 439 mm | 439 mm | 439 mm |
| Wheelbase | 1.113 mm | 1.146 mm | 1.181 mm |
| Bottom Bracket Drop | 29 mm | 29 mm | 29 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 331 mm |
| Fork installation height | 551 mm | 551 mm | 551 mm |
| Fork offset | 46 mm | 46 mm | 46 mm |
| Fork caster | |||
| Travel (rear) | 130 mm | 130 mm | 130 mm |
| Travel (front) | 140 mm | 140 mm | 140 mm |
