Compare these geometries with each other
| Modell | Bianchi Impulso Pro (2022) | Bianchi Impulso Pro (2022) | Bianchi Impulso Pro (2022) | Bianchi Impulso Pro (2022) | Bianchi Impulso Pro (2022) | Bianchi Impulso Pro (2022) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | 480 | 500 | 520 | 540 | 560 | 580 |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 378 mm | 383 mm | 385 mm | 386 mm | 391 mm | 396 mm |
| Stack | 510 mm | 529 mm | 542 mm | 554 mm | 569 mm | 583 mm |
| STR | 1,35 | 1,38 | 1,41 | 1,44 | 1,46 | 1,47 |
| Front-Center | ||||||
| Head Angle | 70.5° | 70.5° | 71° | 71.5° | 72° | 72.5° |
| Seat Angle, effective | ||||||
| Seat Angle, real | 75.5° | 75° | 74.5° | 74° | 73.5° | 73° |
| Top Tube Length | ||||||
| Top Tube Length (horizontal) | 510 mm | 525 mm | 535 mm | 545 mm | 560 mm | 575 mm |
| Head Tube Length | 100 mm | 115 mm | 125 mm | 135 mm | 145 mm | 160 mm |
| Seat Tube Length | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Standover Height | ||||||
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1.009 mm | 1.018 mm | 1.019 mm | 1.020 mm | 1.024 mm | 1.028 mm |
| Bottom Bracket Drop | 53 mm | 58 mm | 60 mm | 60 mm | 62 mm | 62 mm |
| Bottom Bracket Height | ||||||
| Fork installation height | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm | 400 mm |
| Fork offset | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Fork caster | ||||||
| Travel (rear) | ||||||
| Travel (front) |
