Compare these geometries with each other
| Modell | Bianchi Arcadex (2021) | Bianchi Arcadex (2021) | Bianchi Arcadex (2021) | Bianchi Arcadex (2021) | Bianchi Arcadex (2021) |
|---|---|---|---|---|---|
| Frame Size/Setup | XS | S | M | L | XL |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 365 mm | 369 mm | 374 mm | 384 mm | 394 mm |
| Stack | 565 mm | 579 mm | 595 mm | 609 mm | 623 mm |
| STR | 1,55 | 1,57 | 1,59 | 1,59 | 1,58 |
| Front-Center | |||||
| Head Angle | 70.5° | 70.5° | 71° | 71° | 71° |
| Seat Angle, effective | 74.5° | 74° | 73.5° | 73.5° | 73° |
| Seat Angle, real | |||||
| Top Tube Length | 522 mm | 535 mm | 520 mm | 550 mm | 585 mm |
| Top Tube Length (horizontal) | |||||
| Head Tube Length | 120 mm | 135 mm | 150 mm | 165 mm | 180 mm |
| Seat Tube Length | 440 mm | 480 mm | 520 mm | 550 mm | 580 mm |
| Standover Height | |||||
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1.010 mm | 1.018 mm | 1.024 mm | 1.039 mm | 1.054 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Bottom Bracket Height | |||||
| Fork installation height | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Fork offset | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Fork caster | |||||
| Travel (rear) | |||||
| Travel (front) |
