Compare these geometries with each other
| Modell | Arc8 Extra (2020) | Arc8 Extra (2020) | Arc8 Extra (2020) |
|---|---|---|---|
| Frame Size/Setup | S | M | L |
| Typ | Mountainbike | Mountainbike | Mountainbike |
| Wheel Size | 29″ | 29″ | 29″ |
| Reach | 440 mm | 465 mm | 490 mm |
| Stack | 602 mm | 611 mm | 620 mm |
| STR | 1,37 | 1,31 | 1,27 |
| Front-Center | |||
| Head Angle | 64° | 64° | 64° |
| Seat Angle, effective | 76° | 76° | 76° |
| Seat Angle, real | |||
| Top Tube Length | 560 mm | 617 mm | 645 mm |
| Top Tube Length (horizontal) | |||
| Head Tube Length | 90 mm | 100 mm | 110 mm |
| Seat Tube Length | 380 mm | 400 mm | 440 mm |
| Standover Height | 687 mm | 689 mm | 687 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1.199 mm | 1.228 mm | 1.257 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Bottom Bracket Height | |||
| Fork installation height | |||
| Fork offset | |||
| Fork caster | |||
| Travel (rear) | 160 mm | 160 mm | 160 mm |
| Travel (front) | 170 mm | 170 mm | 170 mm |
