3T Exploro Race (2021) - Geometry
Compare these geometries with each other
Die Tabelle lässt sich verschieben.
| Modell | 3T Exploro Race (2021) | 3T Exploro Race (2021) | 3T Exploro Race (2021) | 3T Exploro Race (2021) | 3T Exploro Race (2021) | 3T Exploro Race (2021) |
|---|---|---|---|---|---|---|
| Frame Size/Setup | XXS | 51 | 54 | 56 | 58 | 61 |
| Typ | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike | Gravel-Bike/CycloCross-Bike |
| Wheel Size | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C | 28″ / 700C |
| Reach | 355 mm | 366 mm | 377 mm | 385 mm | 393 mm | 404 mm |
| Stack | 520 mm | 542 mm | 564 mm | 584 mm | 604 mm | 632 mm |
| STR | 1.46 | 1.48 | 1.50 | 1.52 | 1.54 | 1.56 |
| Reach+ | ||||||
| Stack+ | ||||||
| Frame RAD | 630 mm | 654 mm | 678 mm | 699 mm | 721 mm | 750 mm |
| Frame RAAD | 34.3° | 34° | 33.8° | 33.4° | 33.1° | 32.6° |
| Front-Center | ||||||
| Head Angle | 69° | 69.5° | 71° | 72° | 72° | 72° |
| Seat Angle, effective | 74.5° | 74° | 73.5° | 73° | 72.5° | 72.5° |
| Seat Angle, real | ||||||
| Top Tube Length | 506 mm | 526 mm | 546 mm | 566 mm | 586 mm | 606 mm |
| Top Tube Length (horizontal) | ||||||
| Head Tube Length | 125 mm | 147 mm | 161 mm | 180 mm | 201 mm | 232 mm |
| Seat Tube Length | 436 mm | 463 mm | 490 mm | 518 mm | 545 mm | 572 mm |
| Standover Height | ||||||
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 998 mm | 1,008 mm | 1,008 mm | 1,014 mm | 1,024 mm | 1,044 mm |
| FC2RC | 1.40 | 1.43 | 1.43 | 1.44 | 1.47 | 1.52 |
| Bottom Bracket Drop | 79 mm | 79 mm | 77 mm | 77 mm | 75 mm | 75 mm |
| Bottom Bracket Height | ||||||
| Fork installation height | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm | 370 mm |
| Fork offset | ||||||
| Trail | ||||||
| Travel (rear) | ||||||
| Travel (front) |
